Singlet processing capacity: 6~16mm(Straight rebar)
Double processing capacity: 6~12mm(Straight rebar)
Max bending angle: ±180°
Maximum towing speed: 65m/min
Maximum bending speed: 1125°/sec
Length accuracy: ±1mm
Loopback function：NO
Accessories：Air compressor, Lath shelf, line split rack
Optional accessories: Hoops collector, Pay-off
Average power: 9 kw/h
Power: 32kw/380V/50Hz
| Description | Unit | ZWG16B |
| Singlet processing capacity: | mm | 6~16 |
| Double processing capacity: | mm | 6~12 |
| Max bending angle: | ° | ±180 |
| Maximum towing speed: | m/min | 92~115 |
| Maximum bending speed: | °/sec | 1000 |
| Length accuracy: | mm | ±1 |
| Average power: | kw/h | 5.5 |
| Power: | kw | 44.8 |
| Volume: | mm | 4000*1400*1900 |
| Weight: | kg | 1800 |
Product features
1.automaticly straightening
2.automaticly bending
3.automaticly measure
4.automaticly cutting
5.can store more than 100 different graphics
| Model | Work material | Working diameter |
| WG8D | rebar | 4~8 |
| WG12D | rebar | 4~14 |
| WG12B | rebar | 4~14 |
| WG12F | rebar | 4~14 |
| WG14F | rebar | 4~14 |
| WG16F | rebar | 5~16 |
| ZWG16B | Straight bar | 5~16 |
| ZWG25 | Straight bar | 10~25 |
Advantage
1.We have 10 years of production experience, the technology and process are very mature.
2.Vulnerable parts are professionally treated at high temperatures for high strength and wear resistance
3.Double wire processing, excellent efficiency
4.Easy to understand, with intuitive instructions and instructional videos.
5.Intelligent alarm system to prevent misoperation and easy maintenance.
6.High-power motor to ensure working accuracy and speed.
7.The servo motor and drive system is developed and manufactured by PHASE, Italy.
8.High efficiency in the after-sales department, our engineers are always on-line and can help abroad.
Are you a factory?
Yes, we are a factory with 15 years of production experience.
What terms of payment do you support?
We support TT, L/C and cash transactions.
How is it assembled?
We will carry out a comprehensive debugging before delivery, customers can use it directly after connecting the power supply.
Does the working voltage of the machine match ours?
We will install the transformer according to the voltage in the customer's country (additional charge is required).
Can you make a custom machine for us?
Yes, we have independent design ability, can be customized according to customer needs.
What is your lead time?
Our production cycle is less than 25 days. If there is stock, we can deliver the goods within 3 days.
How do you do after sales?
We have detailed teaching videos and support all-weather video remote communication. All non-fragile parts that are damaged for non-human reasons can be replaced free of charge. If customers require, we can also send engineers to the site to deal with problems.
